[Cylinder type sensing head size] M8
[Type] Unshielded
[Sensing method] Inductive type
[Sensing distance] 4mm -10% to 10%
[Setting distance] 0 to 3.2 mm
[Differential distance] 15% Max. of sensing distance
[Sensing object] Ferrous metal (Sensitivity lowers with non-ferrous metals.)
[Standard sensing object] Iron 20*20*1mm
[Response frequency] DC: 1 kHz (average)
[Power supply voltage] 12 to 24 VDC ripple(p-p) :10% Max.
[Operating voltage range] 10 to 30 VDC
[Leakage current] 0.8 mA Max.
[Control output (Output type)] DC 2-wire models with polarity
[Control output (Switching capacity)] 3 to 100mA
[Indicator] Operation indicator(red), Operation setting indicator(green)
[Diagnostic output delay] 0.3 to 1 s
[Operation mode] NO
[Protective circuit] Surge suppressor
Output short-cut protection
[Ambient temperature] Operating: -25 to 70 CEL
Storage: -40 to 85CEL
(with no icing or condensation)
[Ambient humidity] 35 to 95 %RH(with no condensation)
[Temperature influence] /- 15% Max. of sensing distance in temperature range of -25 to 70 CEL
(As the basis for sensing distance of 23CEL)
[Voltage influence] /- 1% Max. of sensing distance in rated voltage range /- 15%. (As the basis for sensing distance at standard power voltage)
[Degree of protection] IEC60529: IP67
[Company standard: Oil-proof
[Connection method] Pre-wired models (Cable length: 2 m)
[Weight (Packed state)] approx. 60 g
